water well of drilling rigs TDD-500 China manufacturer water well drilling

  • water well of drilling rigs TDD-500 China manufacturer water well drilling
  • water well of drilling rigs TDD-500 China manufacturer water well drilling
  • water well of drilling rigs TDD-500 China manufacturer water well drilling
  • water well of drilling rigs TDD-500 China manufacturer water well drilling
Model No.︰TDD-500
Brand Name︰TDD
Country of Origin︰China
Unit Price︰CNY ¥ 360000 / pc
Minimum Order︰1 pc
Share on:

 Total 19 Related Items
Prev1213141516Next

Product Description

    HeBei Thunder Drill Technology Co.,Ltd.   produce drilling rigs ,air compressor,drill rod ,DTH hammer , drill bits etc.

Out products are mainly used for water well , mining , exploration in oil ,gas ,geothermy.

Our company sticks to the idea of "market-oriented,user-centric,quality of survival,innovation for development''.our products have been exported to Russia ,India,Pakistan,Libya,Africa and other countries.

Our company adhere to the tenet of "mutual benefit, common development ,to benefit of the public, contributing to the society" we will do our best to become machinery equipment enterprise with world -class management, technology and quality by continuously improving our products quality.

Thunder Technology will be expert of drill well in China as well as world.

Technical Parameter:

Technical Parameter     Unit   TDD500 TDD500S TDD500A TDD500AL
Max drilling depth M 500 500 500 500
Drilling Diam MM 105-400 105-400 105-400 105-400
Air pressure Mpa 1.05-3.45 1.05-3.45 1.05-3.45 1.05-3.45
Air consumption m3/min 16-55 16-55 16-55 16-55
 Drilling pipe length M 3.5 6 3.5 4.5
 Drilling pipe diam MM 102/114 102/114 102/114 102/114
 Main shaft pressure T 12 12 12 12
Lifting force T 25 25 25 25
 Fast lifting speed m/min 25 20 30 30
Fast forwarding speed m/min 35 40 40 40
 Drilling efficiency m/h 10-35 10-35 10-35 10-35
Max rotary torque Nm 9000 9000 9000 9000
 Max rotary speed r/min 75/150 75/150 95/190 95/190
 Moving speed Km/h 3 3 3.5 3.5
 Climbing capacity Slope 21° 21° 21° 21°
 Drilling rigs weight T 11 12.8 11 12.5
Outer dimensions M 6.8x2.25x2.85 5.6x2.25x2.9 6.8x2.25x2.85 8.1x2.25x2.85
 Working condition loose layer and bedrock
 Drilling method hydraulic rotation and propuision,DTH Hammer drilling ,
Mud Drilling.
 Suitable hammer Medium and high air pressure series.
Product Image
