Hebei Thunder Technology Co., Ltd is a professional manufacturer of filter elements, filter plates, sintered wire mesh, stainless steel wire mesh and black iron wire mesh.
Thunder Technology imports advanced vacuum sintering equipment and technology, specializing in the production of multi-layer stainless steel sintered wire mesh with different structures and specifications, special alloy sintered wire mesh, and the production of various types of filter elements using sintered wire mesh. Products are widely used in petroleum, chemical, aerospace, electronics, pharmaceutical, environmental protection, food and beverage industries.
Thunder Technology has more than 100 advanced shuttleless wire mesh machine, can be produced from 1mesh to 635mesh , weaving types are: Plain Weave, Twilled Weave, Dutch Plain Weave, Dutch Twilled Weave, Reverse Weave, Five Heddle Weave etc, we can meet the needs of different types of customers
Thunder Technology products are exported to the United States, Germany, Australia, Canada, Spain, South Korea and Southeast Asia and other countries and regions, praised by the majority of users.
Thunder Technology has advanced testing equipment and strict quality system to ensure high quality products and services for customers.
Specfication:
|
Mesh/Inch
|
Wire Diameter
|
Aperture
|
Open Area
|
Weight(LB) /100 Square Foot
|
|
|
Inch
|
MM
|
Inch
|
MM
|
|
|
|
1x1
|
.080
|
2.03
|
.920
|
23.37
|
84.6
|
41.1
|
|
2X2
|
.063
|
1.60
|
.437
|
11.10
|
76.4
|
51.2
|
|
3X3
|
.054
|
1.37
|
.279
|
7.09
|
70.1
|
56.7
|
|
4X4
|
.063
|
1.60
|
.187
|
4.75
|
56.0
|
104.8
|
|
4X4
|
.047
|
1.19
|
.203
|
5.16
|
65.9
|
57.6
|
|
5X5
|
.041
|
1.04
|
.159
|
4.04
|
63.2
|
54.9
|
|
6X6
|
.035
|
.89
|
.132
|
3.35
|
62.7
|
48.1
|
|
8X8
|
.028
|
.71
|
.097
|
2.46
|
60.2
|
41.1
|
|
10X10
|
.025
|
.64
|
.075
|
1.91
|
56.3
|
41.2
|
|
10X10
|
.020
|
.51
|
.080
|
2.03
|
64.0
|
26.1
|
|
12X12
|
.023
|
.584
|
.060
|
1.52
|
51.8
|
42.2
|
|
12X12
|
.020
|
.508
|
.063
|
1.60
|
57.2
|
31.6
|
|
14X14
|
.023
|
.584
|
.048
|
1.22
|
45.2
|
49.8
|
|
14X14
|
.020
|
.508
|
.051
|
1.30
|
51.0
|
37.2
|
|
16X16
|
.018
|
.457
|
.0445
|
1.13
|
50.7
|
34.5
|
|
18X18
|
.017
|
.432
|
.0386
|
.98
|
48.3
|
34.8
|
|
20X20
|
.020
|
.508
|
.0300
|
.76
|
36.0
|
55.2
|
|
20X20
|
.016
|
.406
|
.0340
|
.86
|
46.2
|
34.4
|
|
24X24
|
.014
|
.356
|
.0277
|
.70
|
44.2
|
31.8
|
|
30X30
|
.013
|
.330
|
.0203
|
.52
|
37.1
|
34.8
|
|
30X30
|
.012
|
.305
|
.0213
|
.54
|
40.8
|
29.4
|
|
30X30
|
.009
|
.229
|
.0243
|
.62
|
53.1
|
16.1
|
|
35X35
|
.011
|
.279
|
.0176
|
.45
|
37.9
|
29.0
|
|
40X40
|
.010
|
.254
|
.0150
|
.38
|
36.0
|
27.6
|
|
50X50
|
.009
|
.229
|
.0110
|
.28
|
30.3
|
28.4
|
|
50X50
|
.008
|
.203
|
.0120
|
.31
|
36.0
|
22.1
|
|
60X60
|
.0075
|
.191
|
.0092
|
.23
|
30.5
|
23.7
|
|
60X60
|
.007
|
.178
|
.0097
|
.25
|
33.9
|
20.4
|
|
70X70
|
.0065
|
.165
|
.0078
|
.20
|
29.8
|
20.8
|
|
80X80
|
.0065
|
.165
|
.0060
|
.15
|
23.0
|
23.2
|
|
80X80
|
.0055
|
.140
|
.0070
|
.18
|
31.4
|
16.9
|
|
90X90
|
.005
|
.127
|
.0061
|
.16
|
30.1
|
15.8
|
|
100X100
|
.0045
|
.114
|
.0055
|
.14
|
30.3
|
14.2
|
|
100X100
|
.004
|
.102
|
.0060
|
.15
|
36.0
|
11.0
|
|
100X100
|
.0035
|
.089
|
.0065
|
.17
|
42.3
|
8.3
|
|
110X110
|
.0040
|
.1016
|
.0051
|
.1295
|
30.7
|
12.4
|
|
120X120
|
.0037
|
.0940
|
.0064
|
.1168
|
30.7
|
11.6
|
|
150X150
|
.0026
|
.0660
|
.0041
|
.1041
|
37.4
|
7.1
|
|
160X160
|
.0025
|
.0635
|
.0038
|
.0965
|
36.4
|
5.94
|
|
180X180
|
.0023
|
.0584
|
.0033
|
.0838
|
34.7
|
6.7
|
|
200X200
|
.0021
|
.0533
|
.0029
|
.0737
|
33.6
|
6.2
|
|
250X250
|
.0016
|
.0406
|
.0024
|
.0610
|
36.0
|
4.4
|
|
270X270
|
.0016
|
.0406
|
.0021
|
.0533
|
32.2
|
4.7
|
|
300X300
|
.0051
|
.0381
|
.0018
|
.0457
|
29.7
|
3.04
|
|
325X325
|
.0014
|
.0356
|
.0017
|
.0432
|
30.0
|
4.40
|
|
400X400
|
.0010
|
.0254
|
.0015
|
.370
|
36.0
|
3.3
|
|
500X500
|
.0010
|
.0254
|
.0010
|
.0254
|
25.0
|
3.8
|
|
635X635
|
.0008
|
.0203
|
.0008
|
.0203
|
25.0
|
2.63
|
Material: AISI304, AISI 304 L, AISI 316, AISI 316 L etc.
Weave Type: Plain weave, Twilled weave, Plain dutch weave, Twilled dutch Weave, Reverse dutch weave.
Performance : Corrosion-resisting, Wear-resisting, Tear-resisting.
Uses: Mainly used for Separation and Filtration, extensively used in petroleum, chemical industry,
environment protection, mine, airspace, paper-making, electronic, metallurgy etc.Widely used for water, air,liquid filter.
Special size and specification are available according to customers requirement.
Thunder Technology offer professional logistics solution based on LCL and FCL by air, by sea ,also land way.
TDD can provide more suitable products according to the actual needs of customers.
TDD is awarded the national patents on many inventions,TDD continue to increase investment in research and development, technological innovation.
